GD03-10N
The UneoTM pressure sensor series is a Wall Street Journal Technology Award and Edison Award winning ultrathin flexible force sensing sensor suitable for a wide range of human-machine interface measurement from a gentle finger touch to full-body weighing scales. The patent-pending sensor technology employs the latest advances in piezoresistive polymer composite processing and printing-based micromachining technology to enable simple and high-quality linear output in the form of variable conductance (inverse of resistance) that is proportional to the input force.
Operating Characteristics (TA = 25°C unless otherwise noted, F is positive)
Linearity Exceeding 99% over 0 to 10N
Capable of up to 10 Million Actuations
Wide Temperature Range -40°C ~ 65°C
Compatible with Simple Voltage-Divider Readout
Environmentally-Friendly Fabrication
