首頁線上購物 Standard Pressure Sensor GD03-10N

GD03-10N

The UneoTM pressure sensor series is a Wall Street Journal Technology Award and Edison Award winning ultrathin flexible force sensing sensor suitable for a wide range of human-machine interface measurement from a gentle finger touch to full-body weighing scales.

The patent-pending sensor technology employs the latest advances in piezoresistive polymer composite processing and printing-based micromachining technology to enable simple and high-quality linear output in the form of variable conductance (inverse of resistance) that is proportional to the input force.

※ A minimum subtotal of NT$3,000 (exclusive of tax) is required for each order.

Price： 157 (approx. USD5)

Description

Description
Download

Operating Characteristics (TA = 25°C unless otherwise noted, F is positive)
Linearity Exceeding 99% over 0 to 10N
Capable of up to 10 Million Actuations
Wide Temperature Range -40°C ~ 65°C
Compatible with Simple Voltage-Divider Readout
Environmentally-Friendly Fabrication
